Research Facilities

Laboratory for Magnetism and magnetic materials

Sl No. Inst. Name Specification Make Contact Photo
1 Ultrasonic cleaner Max 60 mins, upto 80°C heating TAKASHI, Japan sbedanta@niser.ac.in
2 Spin coater Milman thin films systems Pvt. Ltd sbedanta@niser.ac.in
3 Vacuum Chamber for Pulsed Laser Deposition (PLD) Chamber: 1” size substrates. Provision for mounting smaller size substrates. Accommodate 6 numbers of 1” dia targets. Resistive heater with maximum temperature 850 °C. Evico Magnetics, Germany (microscope part: Zeiss) sbedanta@niser.ac.in
4 Quantum Design Evercool SQUID-VSM
  • Temperature range: 1.8 K – 400 K
  • Magnetic field range -70 kOe to +70 kOe

AC susceptibility specifications:

  • AC frequency range 0.1 Hz to 1 kHz
  • AC amplitude1 (peak) 0.1 Oe to 10 Oe

Ultra-low field specifications:

  • Field uniformity ±0.05 Gauss
  • Target field range -5 Gauss to +5 Gauss
 sbedanta@niser.ac.in
5 Low temperature Magnetoresistance set-up
  • Model: Closed cycle cryostat from Oxford, UK.
  • Temperature 1.7 to 300 K.
  • Field up to 7 Tesla.
Transport and magnetotransport measurements are presently incorporated with Keuthley nanovoltmeter		 sbedanta@niser.ac.in
6 Ferromagnetic resonance set-up
  • Model: FMR set-up procured from NanoOsc.
  • Frequency range 2 to 17 GHz and magnetic field 1.5 kOe.
 sbedanta@niser.ac.in
7 Atomic Force Microscope and/or Magnetic Force Microscope
  • Model: Nano-Observer AFM from Concept Scientific Instrument, France.
  • Modes: Contact and Non-contact modes.
  • Magnetic Field: in-plane magnetic field upto 0.15 T can be applied.
  • Scan Area: ~ 100 µm × 100 µm
  • Resolution: depends on the probe radius.
  • Operating Temperature: Room Temperature.
 sbedanta@niser.ac.in
8 DC/RF magnetron sputtering system: It has 3 RF and 2 DC sputtering target along with 4 pocket e-beam and two port thermal boat facilities. One DC Nanogen sputtering for direct nano-particle synthesis. The base pressure is ~1x10-10 mbar. This system is dedicated for oxide and magnetic materials deposition Mantis Deposition Ltd. UK sbedanta@niser.ac.in
9 Magneto-optic Kerr microscope: Magnetic domain imaging and domain wall movement along with M-H curve for longitudinal, transverse, and polar geometry Evico Magnetics GmbH, Germany sbedanta@niser.ac.in

Thin Film Laboratory

Sl No. Inst. Name Specification Make Contact Photo
1 Modular Thin Film deposition system It is a small UHV chamber with base pressure of ~5x10-7 mbar with 4 pocket e-beam and two port thermal boat facilities. This system is dedicated for metal deposition. Mantis Deposition Ltd. UK pratap.sahoo@niser.ac.in

Non-Linear optics Laboratory

Sl No. Inst. Name Specification Make Contact Photo
1 Lifetime measurement facility using up-conversion based femtosecond-optically-gated (FOG) IOPB facility @ NISER lab: CDP Russia ritwick.das@niser.ac.in
2 High-power continuous-wave fiber laser for studying nonlinear optical interactions IPG Photonics, USA ritwick.das@niser.ac.in
3 High power femtosecond fiber laser for studying ultrafast nonlinearity Fiannium lasers Ltd., UK ritwick.das@niser.ac.in

Ultra Cold Atom Laboratory

Sl No. Inst. Name Specification Make Contact Photo
1 External cavity diode lasers @780 nm (3 units) TOPTICA-DL100, Dl Pro. a.mohapatra@niser.ac.in
2 High power tunable frequency doubled diode laser @480 nm TOPTICA-SHG110 a.mohapatra@niser.ac.in

Experimental Facilities for open-ended higher semester teaching

Sl No. Inst. Name Specification Make Contact Photo
1 Atomic Force Microscope (AFM) Nano Scan Technology Ltd., Russia
2 Scanning Tunneling Microscope (STM) PHYWE
3 Thin film deposition system using resistive heating Hind High Vacuum Co. Pvt.Ltd, Bangalore
4 Keithley high impedance electrometer for 2 probe I-V measurement Keithley Instruments Int. Corp.
5 Raman spectrometer with 785 nm diode laser excitation line, scanning range from 100-2200 cm-1, Optical resolution: 6.5cm-1 Enwave Optronics, Inc. EZRAMAN-M
6 Earth field NMR and MRI system Magritek-Terranova MRI
7 Laser Gyroscope PHYWE
8 Study of He-Ne laser principle and parameters PHYWE
9 Study of Nd-YAG diode laser principle and parameters PHYWE
10 Optical Holography Measurement PHYWE

Common Experimental Facilities

Sl No. Inst. Name Specification Make Contact Photo
1 Field Emission Scanning Electron Microscopy (FESEM) This is dedicated for imaging nano-scale materials. The energy dispersive spectroscopy (EDS) option is also available for elemental analysis of nano or microstructures Carl Zeiss NTS Ltd, UK cl_sps@niser.ac.in
2 Magneto-optic Kerr effect magnetometer (MOKE) in longitudinal and transverse geometry Hinds Instruments, USA cl_sps@niser.ac.in
3 Muffle Furnace Nabertherm, Germany cl_sps@niser.ac.in
4 Glove Box Braun, German cl_sps@niser.ac.in
5 Two Zone Vaccum Furnace Lenton, UK cl_sps@niser.ac.in
6 Photoluminescence cl_sps@niser.ac.in
7 Electroluminescence cl_sps@niser.ac.in
8 Wire bonder cl_sps@niser.ac.in
9 Optical Microscopy Inspection microscope cl_sps@niser.ac.in
10 Spin coater cl_sps@niser.ac.in
11 Photolithography and Mask aligner cl_sps@niser.ac.in
12 Reactive Ion Etching (RIE) Parallel plate plasma cleaner Parallel plate plasma etcher for H. Fillunger & Co. cl_sps@niser.ac.in
13 PECVD RF Plasma enhanced chemical vapour deposition MTI corporation cl_sps@niser.ac.in
14 Ball milling Retsch, Germany cl_sps@niser.ac.in
15 X-ray Diffractometer Thin film diffractometer for GIXRD and XRR etc. Rigaku Smartlab X-Ray diffractometer cl_sps@niser.ac.in
16 Laboratory press for making pellets using SS die Techno search instruments cl_sps@niser.ac.in

Ajaya Kumar Nayak Lab

Sl No. Inst. Name Specification Make Contact Photo
1 PPMS (EverCool II) Cryogen free system for measurement of physical properties, such as, ac susceptibility, heat capacity, electrical transport, thermal transport as a function of temperature (2-400 K) and magnetic field up to 9 T. Quantum Design ajaya@niser.ac.in
2 Arc-melt Furnace Water cooled single Arc vacuum furnace for melting metals and metal alloys up to 20 gm samples in partial inert gas atmosphere. Edmund Buehler ajaya@niser.ac.in

HPC Facilities

Sl No. Inst. Name Specification Make Contact Photo
1 HPC facility (RL514) Intel Xeon 1088 cores 30 TFLOPs  HPC  OEM: Supermicro
Vendor: Netweb		 jbhattacharjee@niser.ac.in
2 Dell precision tower 7910 Processor: Dual Intel Xeon, E5-2699 v4, 2 x 22 core , 55 MB Cache
Memory: Quad channel Memory 4x16 GB, 2400 MHz DDR4 ECC memory.		 Dell victor@niser.ac.in

Experimental High Energy Physics Lab (Heavy-Ion and Dark Matter)

Sl No. Inst. Name Specification Make Contact Photo
1 5 channel gas mixing system
  • Mixture gases – Freon, isobutane, SF6, argon and CO2.
  • Finely tunable mixing ratios depending on flow rate
  • The system can supply gas to 8 detectors simultaneously with a maximum flow rate of 50 sccm per channel
  • Output pressure control
  • Used for research in advanced gaseous detectors like Resistive Plate Chamber (RPC), Gas Electron Multiplier (GEM) etc.
 Excel Gas and Equipments Pvt. Ltd vkashyap@niser.ac.in, bedanga@niser.ac.in
2 VME digitizer based data acquisition system with DPP-PSD and DPP-PHA firmware
  • V1730 digitizer
  • 16 channel
  • 500 MS/s sampling rate
  • Used in research related to neutron detectors for rare event experiments
 CAEN vkashyap@niser.ac.in, bedanga@niser.ac.in
3 Neutron source
  • Encapsulated Am-Be source
  • Activity: 1 mCi
  • Lead bricks, polyethylene and borated polyethylene sheets for shielding
  • Used in research related to neutron detectors for rare event experiments
 Eckert-Ziegler vkashyap@niser.ac.in, bedanga@niser.ac.in
4 Liquid scintillator detectors
  • Dia: 2/", height: 2/"
  • Neutron gamma pulse shape discrimination
  • Fast neutron detection
 Eljen Technology Pvt. Ltd vkashyap@niser.ac.in, bedanga@niser.ac.in
